SL-H2-3316-40 角门铰链
SL-H2-3316-40 为 8PT 型材柜角门铰链，黑色喷粉锌合金与钢结构，内螺纹加螺钉安装：与 8PT 柜体框架系统配套，角门自由摆动、全开无干涉。
- SKU : SL-H2-3316-40
自由摆动铰链让门体在全行程内顺畅转动——多数型号支持 180° 全开，检修空间不受遮挡。角部结构适配折弯钣金门的折角，安装平整且经济；可拆型号支持检修时整体取门。载荷与安装尺寸见图纸。
核心特性
材质: Zinc Alloy, Steel
表面处理: Powder Coating
安装方式: Internal Thread, Screw Mount
载荷等级: Light Duty
符合标准: UL FTTA2 / FTTA8 Class 1, REACH No.1907/2006
应用场景
电气柜与控制柜
折弯钣金柜门与角部结构柜门
机械防护罩与设备罩壳
交通运输与工业车辆设备
requestDrawing.title
requestDrawing.desc
常见问题
查看全部→参考资料
- IEC 62262:2002+A1:2021, Degrees of protection against external mechanical impacts (IK code), International Electrotechnical Commission
- IEC 61373:2010, Railway applications — Rolling stock equipment — Shock and vibration tests, International Electrotechnical Commission
- ASTM B117-19, Standard Practice for Operating Salt Spray (Fog) Apparatus, ASTM International
操作指南
1. Match the 8PT cabinet frame
The 8PT-profile corner door hinge in powder-coated zinc alloy and steel is matched to 8PT cabinet frame systems.
2. Fix through internal threads
Internal threads and screws give a clean, flush attachment on the frame profile.
3. Swing freely over the full range
The hinge carries corner doors with free swing over the full opening range.
4. Check behavior on vibrating equipment
Verify hinge seating and door alignment after transport vibration on mobile or vibrating cabinets.
5. Confirm materials for the site class
Validate the zinc and steel build against the site's salt-spray exposure class.
订购与定制条款
| 起订量 100 件起 | 因产品而异，具体咨询 |
| OEM / ODM 100 件起 | 因产品而异 |
| 样品按实际费用提供 | 无库存约 25 天 |
| 现货 10–15 天 | 生产 15–20 天 |
| T/T 付款 · 24 小时出 PI |
